The Communication Steel Pipe Tower is a cutting-edge structure designed to support wireless communication technologies. Constructed from high-strength steel, it ensures optimal performance and durability in various environmental conditions. Its sleek, tubular design minimizes wind resistance, enhancing stability and safety. This tower is versatile, supporting a wide range of communication equipment for cellular, radio, and television broadcasting. Easy to install and requiring minimal maintenance, it is an essential component for modern communication networks, offering unparalleled reliability and coverage.
| No | Item | Data |
| 1 | High | From 60M-100M or according to client's requirement |
| 2 | Use | Mobile phone signal, traffic satellite positioning system(GPS) and other signal transmission and transmission |
| 3 | Shape | Polygonal or Conical |
| 4 | Material | Normally Q235B/355B/420B/420C...Yeild Strength≥235MPa |
| 5 | Q355B,Yeild Strength≥345MPa | |
| 6 | As well as Hot Rolled coil from ASTM572,GR65,GR50,SS400 | |
| 7 | Tolerance of the dimension | According to client's requirement |
| 8 | Surface treatment | Hot-dip-any other standard by client's requirement |
| 9 | Joint of Poles | Slip joint,flanged connected |
| 10 | Manufacturing standard | GB/T2694-2018 |
| 11 | Wind speed design | 30M/s(varies by region) |
| 12 | Standard | SOI9001:2015 |
| 13 | Length of per section | Within 13M once forming |
| 14 | lce depth | 5mm-7mm (varies by region) |
| 15 | seismic strength | Lv.8 |
| 16 | Preferred temperature | -35 degrees Celsius to 45 degrees Celsius |
| 17 | Vertical direction | <1/1000 |
| 18 | Welding Standard | AWS(American welding Society)D 1.1 |
| 19 | Production Process | Raw material test-cutting-bending-welding-dimension verify-flangewelding-hole drilling-sample assemble-surface clean-galvanization or power coating /painting-recalibration-packages |
| 20 | Packages | according to client's requirement |
| 21 | Life Period | More than 30 years,it is according to installing environment |
Mobile Communication Base Station: Communication steel pipe towers are widely used in the construction of mobile communication networks as key nodes for signal transmission. They provide a high degree of advantage to ensure that wireless communication signals can cover a wider area, thus improving the access quality and speed of the network and meeting the growing demand for mobile communications.
Radio and TV Transmission: In the radio and TV industry, communication steel pipe towers are used to install radio and TV transmission antennas. The height and stability of these towers are critical to ensuring that radio and television signals are transmitted over long distances, allowing radio and television programs to be clearly transmitted to thousands of homes.
Emergency Communication Systems: In emergency situations, such as natural disasters or public safety incidents, communication steel pipe towers provide a support platform for emergency communication systems. They ensure unimpeded communications between rescue teams and are vital for coordinating rescue operations, delivering emergency information and protecting people's lives and property.
Traffic Monitoring and Management: Communication Steel Pipe Towers are also used for traffic monitoring systems, installing traffic cameras and surveillance equipment. The data collected by these devices is important for traffic flow analysis, accident prevention and rapid response, and the implementation of intelligent transportation systems, helping to improve road safety and traffic efficiency.
Strength and Reliability for Modern Networks: When building today's communication networks, you need more than just height — you need strength, reliability, and design that stands the test of time. That's exactly what our Communication Steel Pipe Towers deliver. Crafted from high-strength steel and engineered for modern demands, these structures are more than towers — they are the backbone of your wireless infrastructure.
Aerodynamic Tubular Design with Lower Wind Resistance: The tubular design means less wind resistance and streamlined performance. Because the tower is made of steel pipe sections, the shape coefficient is significantly lower than traditional angle-steel structures. That means when the wind howls, your tower holds steady. Thanks to a larger radius of gyration for the same cross-sectional area, steel pipe towers deliver higher structural capacity while using less material.
Superior Durability and Long Service Life: Durability matters. A communication tower must perform outdoors, in all kinds of weather, for decades. Our towers are hot-dip galvanized (or finished to your specification) and built from steel grades like Q355B with yield strength ≥ 345 MPa (or equivalent). The result is a long service life, minimal maintenance, and reliable performance over time.
Fast and Flexible Installation: Installation speed and flexibility are major advantages. Because the steel pipe sections can be prefabricated and bolted or flanged together on-site, the erection process is faster and more predictable. Compared to complex lattice towers made of numerous members, the tubular design simplifies logistics and assembly, saving both time and labor.
Versatile Applications Across Communication Systems: Versatility is built in. Whether you're mounting cellular antennas, radio and TV broadcasting equipment, emergency-communication systems, or traffic-monitoring devices, our communication steel pipe towers adapt. This single tower solution fits multiple use cases — an advantage when project requirements evolve.
Aesthetic Design and Cost Efficiency: Steel pipe towers take up less visual volume compared to heavy lattice structures, and their smooth lines offer a cleaner look in urban or sensitive environments. The reduced steel consumption (often 10–20 % less) and simplified fabrication also mean cost savings. You get better performance, lower costs, and a more elegant appearance.
